Type

Uncooled Vox(vanadium oxide)

Resolution(pixel)

480*360

Pixel Size(µm)

12*12

NETD

≤20mK（0.02℃）

Frame Rate(Hz)

50

Detection Distance(m)

1800

Image Engine

PARD IREA

Objective Lens(mm)

35

Optical Magnification(x)

2.5

Digital Zoom(x)

2/4/6/8

Field of View (Horizontal)

7.1°

Field of View (Vertical)

7.1°

Field of View (Diagonal)

10.0°

Focus Range

3m-∞

Resolution(pixel)

2560*1440

Pixel Size(µm)

2.9

Sensitivity(lux)

0.001

Frame Rate(Hz)

Color mode: 60 / Mono: 30

Image Engine

PARD VLEA

Objective Lens(mm)

50/70

Optical Magnification(x)

4.4/6.1

Digital Zoom(x)

2

Field of View (Horizontal)

4.8°/3.4°

Field of View (Vertical)

4.8°/3.4°

Field of View (Diagonal)

6.8°/4.8°

Focus Range

3m-∞

Type

IPS

Resolution(pixel)

800*800

Reticle Style

6

Reticle Color

4(Red/White/Yellow/Green)

Scene Mode

City/Rain/Forest

Image Mode

WT-HOT/BK-HOT/EDGE/RD-HOT/IN-HOT/SKY

Eye Relief(mm)

100

Diopter Adjustment(D)

-5~+3

Photo Resolution(pixel)

1536*1536

Photo Format

.JPG

Video Resolution(pixel)

Thermal: 768*768/Night Vision: 1440*1080

Video Format

.mp4

Scene Mode

City, Rain, Forest

Storage(GB)

Micro SD card (Max. 128)

LRF Detection Range(yd/m)

1200/1000

Ballistic Calculator

Yes

PIP

Yes

Gyroscope

Yes

Loop Recording

Yes

Recoil-activated Recording

Yes

E-compass

Yes

Shutter

Mechanical shutter

Microphone

Yes

Firmware Upgrade

Yes

IR Power(W)

5

IR Illuminating Level

3 Levels

IR Distance(m)

350

IR Wavelength(nm)

850/940

USB Type-C

Yes

HDMI Output

Yes

WiFi

Yes

Supported Apps

PardVision2

Battery Type

Li-ion 21700*1

Output Voltage(V)

3.7

Operating Time(h)

≤6

External Power Supply

Type-C

Degree of Protection

IP67

Operating Temp(°C/°F)

-30 ~ +55 / -22 ~ +131

Recoil Resistance(J)

6000

Housing

Aluminium Alloy

Objective Lens

All-glass multi-coated lens

Product Dimension(L x W x H, mm)

265*92*90

N.W/pcs(with IR illuminator&LRF&battery, g)

750
