HIKMicro Lynx PRO 25mm Smart Thermal Monocular

HIKMICRO
SKU:
HM-LH25
£1,399.99 £1,299.99
(No reviews yet)
Current Stock:
Adding to cart… The item has been added

LYNX Pro LH25


Handheld Thermal Monocular Camera

Watch the Video here.


HIKMICRO LYNX Pro LH25

LYNX Pro LH25
Handheld Thermal Monocular Camera
HikMicro LYNX Pro LH25 handheld thermal monocular camera is equipped with a 384 × 288 infrared detector and a 1280 ×
960 LCOS display. It supports functions of observation, distance measurement, Wi-Fi hot spot, and so on. The high-sensitivity
built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly applied to scenarios
such as patrolling, searching and rescuing, hiking, travel, and hunting, etc.


Key Features


● 384 × 288 resolution, 12 μm, high sensitivity detector
● Adaptive AGC, DDE, 3D DNR, NETD less than 35 mk (@25°C), F#=1.0
● 1280 × 960 resolution 0.4-inch LCOS display
● Built-in rechargeable lithium battery
● Up to 7.5 hours continuous running
● Wi-Fi hot spot
● Type-C Interface

Specification


Thermal Module


Image Sensor Vanadium Oxide Uncooled Focal Plane Arrays
Max. Resolution 384 × 288
Pixel Interval 12 μm
Response Waveband 8 μm to 14 μm
NETD less than 35 mk (@25°C), F#=1.0
Lens (Focal Length) 25 mm
Field of View 10.5° × 7.9° (H × V)
Digital Zoom 1 ×, 2 ×, 4 ×, 8 ×
Aperture F1.0
Magnification 2.45 to 19.6


Image Display


Monitor 0.4 inch, LCOS, 1280 × 960
FFC (Flat Field Correction) Auto, Manual, External Correction
Palettes Black Hot, White Hot, Red Hot, Fusion
Frame Frequency 50 Hz
Smart Function
Wi-Fi Hot Spot Yes
Standby Mode Yes
Detection Range 1180 m


System


Storage Built-in memory module (8 GB)
Record Video Yes
Capture Snapshot Yes
Power Supply
Battery Type Lithium battery
Battery Operating Time
7.5 hours continuous running with Wi-Fi hot spot function off (@25°C)
6 hours continuous running with Wi-Fi hot spot function on (@25°C)
Battery Capacity Display Yes


General


Power 5 VDC/2 A, 1.5 W, Type-C Interface
Working Temperature -20 °C to 55 °C (-4 °F to 131 °F)
Protection Level IP67
Dimension 171 mm × 61 mm × 57 mm (6.73" × 2.40" × 2.24")
Weight 300 g (0.66 lb)
