HIKMICRO

HIKMicro Lynx PRO 15mm Smart Thermal Monocular

HIKMicro Lynx PRO 15mm Smart Thermal Monocular

SKU:HM-LH15

Regular price £939.99 GBP
Regular price £999.99 GBP Sale price £939.99 GBP
Sale Sold out
Tax included.

Please be aware Air weapons & silencers are restricted and cannot be delivered to your address (unless delivered locally). These items will need to be collected or sent to your nearest gunshop for collection. Photo ID Required.

LYNX Pro LE15


Handheld Thermal Monocular Camera

Watch the Video here.


HIKMICRO LYNX Pro LE15 handheld thermal monocular camera is equipped with a 256 × 192 infrared detector and a 720
× 540 LCOS display. It supports functions of observation, distance measurement, Wi-Fi hot spot, and so on. The
high-sensitivity built-in thermal detector provides you with clear view even in total darkness. The monocular is mainly
applied to scenarios such as hunting, hiking, law enforcement, searching and rescuing, and etc.


Key Features


 256 × 192 resolution, 12 μm, high sensitivity detector
 Adaptive AGC, DDE, 3D DNR, NETD less than 35 mK (@ 25 °C), F# = 1.0
 720 × 540 resolution 0.2-inch LCOS display
 Built-in rechargeable lithium battery
 Up to 8 hours continuous running
 Hot Spot
 Type-C Interface

Specification


Thermal Module


Image Sensor................VOx Uncooled Focal Plane Arrays
Max. Resolution....... ......256 × 192
Pixel Interval................. 12 μm
Response Waveband.......... 8 μm to 14 μm
NETD.......................... Less than 35 mK (@ 25 °C),F# = 1.0
Lens ..........................(Focal Length.......//) 15 mm
Field of View ...................11.69° × 8.78° (H × V)°
Digital Zoom ..................1 ×, 2 ×, 4 ×, 8 ×
Aperture ........................F1.0
Magnification ..................1.42 to 11.36


Image Display

Display........................... 0.2 inch, LCOS, 720× 540
FFC ................................(Flat Field Corre................ction) Mode Auto, Manual, External Correction
Palettes.......................... Black Hot, White Hot, Red Hot, Fusion
Frame Frequency.............. 25 Hz
Smart Function
Hot Spot.......................... Yes
Standby Mode................... Yes
Detection Range................ 708 m
System
Built-in Memory................. 8 GB
Built-in Memory Capacity ....220,000 pictures
Record Video..................... Yes
Capture Snapshot............... Yes


Power Supply


Battery Type....................... Lithium battery
Battery Operating Time
.........................................8 hours continuous running with Wi-Fi hot spot function off (@ 25 °C)
.........................................6 hours continuous running with Wi-Fi hot spot function on (@ 25 °C)
Battery Capacity Display........ Yes


General


Power................................... 5 VDC/2 A, 1.5 W, Type-C Interface
Work Temperature.................. - 20 °C to 55 °C (- 4 °F to 131 °F)
Protection Level ......................IP67
Dimension ..............................158.3 mm × 61 mm × 57 mm (6.23" × 2.40" × 2.24")
Weight ...................................280 g (0.62 lb)
